Technological Process

Steel Wheel
Aluminium Wheel

Rim Technological Process Route

Disc Technological Process Route

Assemble Technological Process Route

Painting Technological Process Route

Blanking - Pickling - Lettering - Rolling - Planishing - Butt Welding - Plane Slag - Rolling Depression - End-Grain Cutting - Polishing - Expanding - First Rolling - Second Rolling - Third Rolling - Expanding - Air Tightness Testing - Inflating Valve Hole - Valve Hole Burring
Blanking
Pickling
Lettering
Rolling
Planishing
Butt Welding
Plane Slag
Rolling Depression
End-Grain Cutting
Polishing
Expanding
First Rolling
Second Rolling
Third Rolling
Expanding
Air Tightness Testing
Inflating Valve Hole
Valve Hole Burring
Blanking - Pickling - Spinning - Flatness Finishing - Punching Central Bore - Punching Vent Hole - Chamfer The Vent Hole - Nut Hole Expanding - Chamfer The Nut Hole - Turning The Outside Diameter And Height Extensively - Turning The Outside Diameter And Central Bore Intensively - Turning The Flatness
Blanking
Pickling
Spinning
Flatness Finishing
Punching Central Bore
Punching Vent Hole
Chamfer The Vent Hole
Nut Hole Expanding
Chamfer The Nut Hole
Turning The Outside Diameter And Height Extensively
Turning The Outside Diameter And Central Bore Intensively
Turning The Flatness
Press And Assemble - Detect Lateral-Radial Runout - Spot Welding - Welding And Compounding - Detect The Welding Seam - Detect Lateral-Radial Runout - Detect The Balance
Press And Assemble
Detect Lateral-Radial Runout
Spot Welding
Welding And Compounding
Detect The Welding Seam
Detect Lateral-Radial Runout
Detect The Balance
Pickling - ED Electrophoretic Coating - Finishing Coat - Install Valve - Stack Pallet - Packing
Pickling
ED Electrophoretic Coating
Finishing Coat
Install Valve
Stack Pallet
Packing

Material Technological Process Route

Forging and Spinning

Heating Treatment

Machining

Cleaning and Packing

Aluminum Bar Stock Cutting - Bar Stock Heating
Aluminum Bar Stock Cutting
Bar Stock Heating
Forging - Spinning
Forging
Spinning
T6 Heating Treatment
T6 Heating Treatment
CNC Machining
CNC Machining
Cleaning - Inspection - Packing
Cleaning
Inspection
Packing

R&D Technology

Producing-Educating-Researching Cooperation With Universities
Proprietary Intellectual Property Rights
Laboratory Equipment
  • Testing Equipment for Material Properties
  •  Wheel Radial Fatigue Testing Machine
  • Wheel Cornering Fatigue Testing Machine
  • Salt Spray Testing Machine
2
3

Quality System

Innovation and Development

The lightweight of vehicles is the development trend of vehicle manufacturing industry; automobile wheel is the key component of vehicle running. Our company had co-researched and made solid cooperative relations with Shougang Group. The current 22.5x8.25 specification 15°DC steel wheel made of 6mm-380CL wheel steel have been in batch use in the US market for more than 10 years, and never occurred any quality problems.



General rim with 6mm-380CL, using the existing continuous flash butt-welding equipment can ensure the welding quality and pass rate. Light weight rim are made of 5mm-590CL materials, as with existing continuous flash butt welding equipment, heat affected zone flaring, dilatation and thinning cracking are very easy to occur. After technology upgrades of research and development, and by using pulse flash butt welding machine, our company’s lightweight wheel cracking rate was reduced from 10%-23% to 1.0%.
